Stainless Steel Rope Mesh
Material: Stainless Steel 304, 304L, 316, 316L;
Cable Construction: 7 × 7 , 7 × 19;
Wire: 1.2mm, 1.6mm, 2.0mm,2.4mm, 3.2mm,etc.;
Mesh Opening: 20*20mm,25.4*25.4mm,38*38mm,51*51mm,60*60mm,76*76mm, 90*90mm, 102*102mm,etc.;
Mesh Opening angles: 20°, 30°, 60°, 70°, 75°. Mesh aperture at 60° as standard opening;
Height: 0.5m,0.8m,1m,1.2m,3m,etc.;
Length: 3m,5m, 10m,15m, 20m,25m, 30m per roll;
Type: Woven Type, ferrule type;
Classification :
Cable diameter | Mesh opening size | Nominal break | ||
inch | mm | inch | mm | lbs. |
1/8 | 3.2 | 4x4 | 102x102 | 1600 |
1/8 | 3.2 | 3x3 | 76x76 | 1600 |
1/8 | 3.2 | 2x2 | 51x51 | 1600 |
3/32 | 2.4 | 4x4 | 102x102 | 920 |
3/32 | 2.4 | 3x3 | 76x76 | 920 |
3/32 | 2.4 | 2x2 | 51x51 | 920 |
5/64 | 2.0 | 3x3 | 76x76 | 676 |
5/64 | 2.0 | 2x2 | 51x51 | 676 |
5/64 | 2.0 | 1-1/2x 1-1/2 | 38x38 | 676 |
1/16 | 1.6 | 3x3 | 76x76 | 480 |
1/16 | 1.6 | 2x2 | 51x51 | 480 |
1/16 | 1.6 | 1-1/2x 1-1/2 | 38x38 | 480 |
1/16 | 1.6 | 1x1 | 25.4x25.4 | 480 |
3/64 | 1.2 | 1-1/2x 1-1/2 | 38x38 | 270 |
3/64 | 1.2 | 1x1 | 25.4x25.4 | 270 |
3/64 | 1.2 | 4/5x4/5 | 20x20 | 270 |
